So this is giving me fits.

CAD & CAM Tool Chain LaserWeb/CNCWeb Suppport
1

So this is giving me fits.

The silhouette on the left of this engraving is a solid black “clipart” type image. There is no shading at all.

When I burn it, I’m getting fade on the left and right of the burn. It does fine with short burns like the the lightning bolt, but when it does prolonged burns I get a sharp outline then fade in, then fade out then a sharp outline again.

I’m burning at 600/600 @ 20% so I don’t burn through this paper thin veneer. Anything slower and it burns through and anything lighter and I don’t get much of a mark (@raykholo I need to touch base with you on the 3.3v thing again)

Thoughts?

The PNG is attached. It’s 300dpi since I forgot to change it after doing some small text engraving.

3082036eb5739f47cc3d87a674054f38.png2078×663 42 KB

527b5e980e8a31d101802dcc16fb3bc0.jpeg960×912 82.9 KB

3e6131941671ac9ce0f166df843383de.jpeg960×540 38 KB

2

I’m not able to lower on the power by the way. We’re having problems ironing out a few kinks with the Cohesion3D board I’m using. Anything below 20 just doesn’t burn.

3

First of all “I love your work”

4

I beleive 600 is to fast for that power specially if you are not getting something bellow 20. I feel you are getting a darker on the narrower bolt as heat is concentrated in a tighter space.

5

@Ariel_Yahni_UniKpty Thanks for the kudos on the work. As for the speed, I bumped it to 600 because I couldn’t get a lower power. I guess we still have some work to do on this board configuration. I really need to get down to about the 10% range and drop it down to around 400 if I can but even that might be cutting it close. this veneer is pretty thin. Think card stock paper thickness.

6

I get you. I’m playing with same type of veneer I got lately. You need to get the power can you post your config somewhere to have a look?

7

Keep me posted.

8

FWIW I noticed that when I import PNG into LW3 it dithers the edges of otherwise perfectly white black transitions. Looking at the PNG in gimp I see no dithering. I think it maybe a function of the PNG import library (not specifically LW3).

9

Interesting. I have the SVG but then it wants to vector engrave it which isn’t what I want in this case. I guess I could try a different export format

10

Do bmp or jpg

11

I think I saw it too with JPG. I have not tried BMP.

12

BTW you can see it in the imported preview image and the generated gcode.

13

@Carl_Fisher ​ can you supply an actual link to the image I would love to try it out. Social media image uploads tend to downgrade images for performance reasons

14

+Peter van der Walt​ is posted with it… took me a minute to see that he uploaded 3 pictures… the source is just really wide not showing the other 2 images

15

I’m hoping he will post the original source file… not sure how Google + alters images when you post them on here… I know Facebook will butcher the heck out of a photo

16

I’ll post the original svg later today. Painting rooms right now to knock some stuff off my honey do list.

17

Will do later. Need to be in front of the config first.

18

Let’s see if this works. Here is the original SVG https://www.dropbox.com/sh/xb4q0hrcfh1m176/AACawyLWz27wu_s6IGdPD3AGa?dl=0

19

I put my config in the same file. keep in mid we’re doing something a bit different with the fire pin

20

I answered the tickle power in the other thread. There wasn’t a setting for it in my config. I have since put one in and set it to 0.0 per the k40 guide

resolution on that particular burn was 300. I had it set there from doing some small text engraving and forgot to set it back to 90 (Inkscape)

acceleration is set to the default 3000
