// Glediator to WS2812 pixel converter #
// by R. Heller #
// V 1.0 - 07.01.2014 #
// http://wwww.SolderLab.de #
// #
// Receives serial data in Glediator protocol format @ 1 MBit/s #
// and distributes it to a connectect chain of WS2812 pixels #
// #
// Adjust the correct DATA PIN and the correct NUMBER OF PIXELS you are using #
// in the definitions section below before uploading this sketch to your #
// Arduino device. #
// #
// Maxiumim number of supported pixeles is 512 !!! #
// #
// In the Glediator software set output mode to “Glediator_Protocol”, #
// color order to “GRB” and baud rate to “1000000” #
// #
//##############################################################################
//##############################################################################

//##############################################################################
// #
// Definitions → Make changes ONLY HERE #
// #
// To find out the correct port, ddr and pin name when you just know the #
// Arduino’s digital pin number just google for “Arduino pin mapping”. #
// In the present example digital Pin 6 is used which corresponds to “PORTD”, #
// “DDRD” and “6”, respectively. #
// #
//##############################################################################

#define DATA_PORT PORTD
#define DATA_DDR DDRD
#define DATA_PIN 8
#define NUMBER_OF_PIXELS 40

//##############################################################################
// #
// Variables #
// #
//##############################################################################

unsigned char display_buffer[NUMBER_OF_PIXELS * 3];
static unsigned char *ptr;
static unsigned int pos = 0;

volatile unsigned char go = 0;

//##############################################################################
// #
// Setup #
// #
//##############################################################################

void setup()
{
// Set data pin as output
DATA_DDR |= (1 << DATA_PIN);

// Initialize UART
UCSR0A |= (1<<U2X0);
UCSR0B |= (1<<RXEN0) | (1<<TXEN0) | (1<<RXCIE0);
UCSR0C |= (1<<UCSZ01) | (1<<UCSZ00) ;
UBRR0H = 0;
UBRR0L = 1; //Baud Rate 1 MBit (at F_CPU = 16MHz)

ptr=display_buffer;

//Enable global interrupts
sei();
}

//##############################################################################
// #
// Main loop #
// #
//##############################################################################

void loop()
{
if (go==1)
{
cli();
ws2812_sendarray(display_buffer, NUMBER_OF_PIXELS * 3);
sei();
go=0;
}
}

//##############################################################################
// #
// UART-Interrupt-Prozedur (called every time one byte is compeltely received) #
// #
//##############################################################################

ISR(USART_RX_vect)
{
unsigned char b;
b=UDR0;

if (b == 1) {pos=0; ptr=display_buffer; return;}
if (pos == (NUMBER_OF_PIXELS*3)) {} else {ptr=b; ptr++; pos++;}
if (pos == ((NUMBER_OF_PIXELS
3)1)) {go=1;}
}

//##############################################################################
// #
// WS2812 output routine #
// Extracted from a ligh weight WS2812 lib by Tim (cpldcpu@gmail.com) #
// Found on http://wwww.microcontroller.net #
// Requires F_CPU = 16MHz #
// #
//##############################################################################

void ws2812_sendarray(uint8_t *data,uint16_t datlen)
{
uint8_t curbyte,ctr,masklo;
uint8_t maskhi = _BV(DATA_PIN);
masklo =~ maskhi & DATA_PORT;
maskhi |= DATA_PORT;

while (datlen-)
{
curbyte = *data++;

asm volatile
(
  "		ldi %0,8	\n\t"		// 0
  "loop%=:out %2, %3	\n\t"		// 1
  "lsl	%1		\n\t"		// 2
  "dec	%0		\n\t"		// 3
  "		rjmp .+0	\n\t"		// 5
  "		brcs .+2	\n\t"		// 6l / 7h
  "		out %2,%4	\n\t"		// 7l / -
  "		rjmp .+0	\n\t"		// 9
  "		nop		\n\t"		// 10
  "		out %2,%4	\n\t"		// 11
  "		breq end%=	\n\t"		// 12      nt. 13 taken
  "		rjmp .+0	\n\t"		// 14
  "		rjmp .+0	\n\t"		// 16
  "		rjmp .+0	\n\t"		// 18
  "		rjmp loop%=	\n\t"		// 20
  "end%=:			\n\t"
  :	"=&d" (ctr)
  :	"r" (curbyte), "I" (_SFR_IO_ADDR(DATA_PORT)), "r" (maskhi), "r" (masklo)
);

}

}

//##############################################################################
// #
// End of program #
// #
//##############################################################################


I ask for help glediator + arduino mega 2560 r3 + ws2812b
but no rx flashing light

Very cool @Rene_Muder ​. Thanks for sharing. It looks like G+ might be messing up the formatting of the code. Could you post it to http://pastebin.com?

Hey Marc all the info on the site and the code! http://www.solderlab.de/index.php/software/glediator
